334/S2322 pump section for JCB TLT 35D (Serial no's 01539000 - 01541999),

334/2322 Hydraulic Pump section

Key Information.

Pump displacement: 12 cc/rev

Replaces rear pump section for the following JCB part numbers

333/W2430

333/W2431

333/S7584

332/S9644

333/S7578

332/S4797

PRODUCTS AFFECTED:
TLT 25D (Serial no's 01539000 - 01541999)
TLT 30D (Serial no's 01539000 - 01541999)
TLT 30D 4x4 (Serial no's 01539000 - 01541999)
TLT 35D (Serial no's 01539000 - 01541999)
TLT 35D 4x4 (Serial no's 01539000 - 01541999)

Weight

• 5KG

When reassembling pump 4 x bolts torque to 48Nm +/- 4Nm
