20/925498 Genuine Parker / JCB 524 /527 Twin Hydraulic Pump 37 + 14CC/REV 20/925498 Genuine Parker / JCB 524 /527 Twin Hydraulic Pump 37 + 14CC/REV

Key Information

• Rotation: Clockwise (looking from shaft end)
• 7/8” Diameter 13T SAE B splined shaft
• SAE B 2 hole mounting flange
• Front Pump displacement: 37 cc/rev (37L/Min per 1000 rpm)
• Rear Pump displacement: 16 cc/rev (14L/Min per 1000 rpm)
• 1 7/8" UNF threaded inlet
• Front pump 1 1/16" UNF threaded outlet
• Rear pump 7/8" UNF threaded outlet

Replaces the following JCB part numbers

• 20/925498


Machine Fitment

• REAR TOW HITCH HYDRAULIC CIRCUIT 524-50 Tier 2 9812/7210

• REAR TOW HITCH HYDRAULIC CIRCUIT 527-55S 9802/7220

•  REAR TOW HITCH HYDRAULIC CIRCUIT 527-55 9802/7220

• REAR TOW HITCH HYDRAULIC CIRCUIT 527-55S Tier 2 9812/7210

• REAR TOW HITCH HYDRAULIC CIRCUIT 524-50 9802/7220

• REAR TOW HITCH HYDRAULIC CIRCUIT 527-55 Tier 2 9812/7210

• TOW HITCH HYDRAULIC CIRCUIT 524-50 9802/7220
• TOW HITCH HYDRAULIC CIRCUIT 527-55S 9802/7220

• TOW HITCH HYDRAULIC CIRCUIT 527-55S Tier 2 9812/7210
• TOW HITCH HYDRAULIC CIRCUIT 524-50 Tier 2 9812/7210

• TOW HITCH HYDRAULIC CIRCUIT 527-55 9802/7220

• TOW HITCH HYDRAULIC CIRCUIT 527-55 Tier 2 9812/7210

• TOW HITCH MANUAL CIRCUIT 527-55 Tier 2 9812/7210

• TOW HITCH MANUAL CIRCUIT 527-55 9802/7220

• TOW HITCH MANUAL CIRCUIT 527-55S Tier 2 9812/7210

• TOW HITCH MANUAL CIRCUIT 527-55S 9802/7220

• TOW HITCH MANUAL CIRCUIT 524-50 Tier 2 9812/7210

• TOW HITCH MANUAL CIRCUIT 524-50 9802/7220

• PUMP,GEAR,TANDEM 524-50 Tier 2 9812/7210

• PUMP,GEAR,TANDEM 527-55S 9802/7220

• PUMP,GEAR,TANDEM 527-55S Tier 2 9812/7210

• PUMP,GEAR,TANDEM 527-55 Tier 2 9812/7210

• PUMP,GEAR,TANDEM 524-50 9802/7220
• PUMP,GEAR,TANDEM 527-55 9802/7220
